Time Fluidity - Page 10

Fluidity 2014-2015
- 10 -
Important: The compression plug is specific to the TIME Fluidity module
No other model is compatible
Important: do not over-tighten the stem. It could cause permanent damage to the steerer tube.
Important: detailed assembly instructions for the TIME MONOLINK Full carbon stem are available
Clearance between
0.5 and 2 mm
Figure 7
Max. torque
5 Nm
Figure 8
