Time Fluidity - Page 24

Fluidity 2014-2015
- 24 -
- rivet using suitable riveting pliers (fig.30)
Check the position of the holder: The retaining clip must be on the left hand side of the bike
(forward-facing)
- Once the stem is fitted to the frame, you will be able to attach the SM-EW90-A or SM-EW90-B
Junction Box (fig.31)
Retaining clip
Figure 30
Figure 31
