Fluidity 2014-2015
- 3 -
Construction of the TIME NXR Instinct module:
Technical specifications:
- Wheel diameter 700C
- Max tyre section 700 x 25
- Front hub width 100 mm
- Rear hub width 130 mm
- Bottom bracket width 68 mm
- Bottom bracket BB 30
- Double chainline 43.5 mm
- Triple chainline 46.5 mm
- Seat post Ø 31.6
- Front derailleur type Braze-on
- Rear derailleur hanger M10 x 100
- Brakes Standard
calipers
(Road 39/50)
- Headset Integrated
Note: The TIME Fluidity module is EN 14781-compliant
It is protected by the following patents:
- Quick Set headset: EP 1 569 843 and US 7 237 787
- Multi-diameter steerer tube: FR 2 807 382 and US6 805 372
- Composite steerer tube: EP 1 015 301
SAFETY INFORMATION
TIME modules are leading-edge products that have all the safety guarantees for their intended use.
Please read the following instructions carefully to ensure safe use.
Tightening torques:
Torque to the recommended values for optimum operation and safety.
Use a good quality torque wrench
- Seat clamp = 8 Nm (rear screw)
- Seat collar = 5 Nm
- Stem rear = 5 Nm (Steerer tube)
- Stem front = 6 Nm (Handlebar)
- Brake nuts = 6 Nm
- Front derailleur hanger = 6 Nm
Construction
Frame
Integral HR carbon RTM+
Vectran® fibres
VIBRASER technology
Fork
Integral specific carbon
Light alloy dropouts
Stem (option)
Monolink Full carbon RTM specific
carbon
Seat post
Standard Ø 31.6
Headset
Quick Set with differentiated ball
bearings
Accessories
Compression plug
Stem spacer set
Front and rear brake nuts
Cable grommet under bottom bracket
Quick Set adjustment levers
Cable housing guards (x2)
Brake cable o-rings (x3)
Protective cable housing
