Titan 340 - Parts List; Parts Listings; Main Assembly

18 © Titan Tool Inc. All rights reserved.
Parts List
Main Assembly
1
2
3
5
6
7
4
8
9
10
11
5
Item Part # Description Quantity
1 704-181 Screw..........................................................4
2 704-232 Motor cover.................................................1
3 ---------- Motor assembly ..........................................1
4 704-179 Left leg assembly........................................1
5 761-178 Screw..........................................................4
6 704-185 Fluid section assembly ...............................1
Item
Part # Description Quantity
7 704-117 Screw..........................................................2
8 ---------- Gear box assembly.....................................1
9 704-178 Right leg assembly .....................................1
10 700-258 PRIME/SPRAY valve assembly..................1
11 704-300 Suction set assembly..................................1
