9.3 Greasing
See the diagram for the location of all grease zerks.
Location Qty.
Receiver Swivel 1
Hitch Pivot Bushings 2
Front Driveline CV Joint 2
Front Driveline U-Joints 3
Wing Driveline U-Joints 4
Splitter Cross Shaft U-Joints 2
Tailwheel Hubs 8
Wing Turnbuckles 2
Use an SAE multipurpose high-temperature grease
with extreme pressure (EP) performance. Also
acceptable is an SAE multipurpose lithium base
grease.
1. Always use a handheld grease gun for all greasing.
2. Wipe grease zerks with a clean cloth before
greasing to avoid injecting dirt and grit.
3. Apply grease until new grease can be seen coming
out of the joint.
4. Do not let excess grease collect on or around parts,
particularly when operating in sandy areas.
5. Replace broken grease zerks immediately.
6. If any grease zerk will not take grease, remove
and clean it thoroughly. Also clean the lubricant
passageway. Replace the zerk if necessary.
