1.4 Specifications
Model 3515
Cutting Width 15'
Cutting Height 2” to 15”
Overall Width 188”
Transport Width 90"
Hitch
Swivel Pivot Self
Leveling
Underneath Deck Heavily Braced
Minimum Tractor PTO 60 HP
Deck Thickness 10 Gauge
Side Skirt 1/4” x 13.5”
Approximate Weight
5600 LBS w/ 6 26"
Laminated Tire
Approximate Tongue
Weight
1900 LBS
Blade Tip Speed 17,135 FPM
Blade Overlap 6”
PTO Driveline ASAE Cat 6
Wing Flex
22 degrees down to 100
degrees up
Splitter Gearbox Rating 235 HP
Outboard Gearbox Rating 190 HP
Gearbox Warranty 5 Year Limited
Machine Warranty 1 Year Limited
Cutting Capacity 3.5”
Cutter Suspension
2 Heavy Duty springs
positioned on the center
tail wheel axle
Safety Tow Chain Standard
Chain Guards Standard
Skid Shoes Replaceable
Wheel Options
20” Laminated Tire
26” Laminated Tire
26” Foam Filled Aircraft
Tires
29” Pneumatic Aircraft
Tires
Specications subject to change without notice.
1.5 Intended Usage
Do not use this rotary cutter for any other purpose than
its intended use of cutting grass, weeds, and brush.
1.6 Operator Orientation
The directions left, right, front, and rear, as mentioned
throughout this manual, are as seen from the tractor
operator’s seat and facing in the direction of travel.
1.7 Serial Number Location (Typical)
The serial number decal is located on the left front of
the center deck.
Serial Number ______________________________
