Titan XT290 - Troubleshooting and Maintenance; Common Sprayer Problems and Solutions

English
22
Title
Troubleshooting / Maintenance
Problem
A. The sprayer does not start.
B. The sprayer starts but does
not draw in paint when the
PRIME/SPRAY knob is set to
PRIME.
C. The sprayer draws up paint
but the pressure drops when
the gun is triggered.
D. The PRIME/SPRAY valve is
on SPRAY and there is ow
through the return tube.
E. The spray gun leaks.
F. The tip assembly leaks.
G. The spray gun will not spray.
H. The paint pattern is tailing.
Cause
1. The sprayer is not plugged in.
2. The ON/OFF switch is set to OFF.
3. The sprayer was turned off while still under
pressure.
4. No voltage is coming from the wall plug.
5. The extension cord is damaged or has too
low a capacity.
6. A fuse is blown in the sprayer.
7. There is a problem with the motor.
1. The unit will not prime properly or has lost
prime.
2. The paint bucket is empty or the suction
tube is not totally immersed in the paint.
3. The suction set is clogged.
4. The suction tube is loose at the inlet valve.
5. The inlet valve is stuck.
6. The inlet valve is worn or damaged.
7. The PRIME/SPRAY valve is plugged.
1. The spray tip is worn.
2. The suction set screen is clogged.
3. The gun lter is plugged.
4. The paint is too heavy or coarse.
5. The inlet valve assembly is damaged or
worn.
1. The PRIME/SPRAY valve is dirty or worn.
1. Internal parts of the gun are worn or dirty.
1. The tip was assembled incorrectly.
2. A seal is worn.
1. The spray tip or the gun lter is plugged.
2. The spray tip is in the CLEAN position.
1. The pressure is set too low.
2. The gun, the tip, or the suction lter is
plugged.
3. The suction tube is loose at the inlet valve.
4. The tip is worn.
5. The paint is too thick.
6. Pressure loss.
Solution
1. Plug the sprayer in.
2. Turn the ON/OFF switch to ON.
3. Slide the PressureTrac™ to maximum pressure
(+), or relieve pressure by turning the PRIME/
SPRAY valve to PRIME.
4. Properly test the power supply voltage.
5. Replace the extension cord.
6. Take sprayer to Authorized Service Center.
7. Take sprayer to Authorized Service Center.
1. Try to prime the unit again.
2. Rell the bucket or immerse the suction tube in paint.
3. Clean the suction set.
4. Clean the tube connection and tighten it securely.
5. Clean the inlet valve. Inlet may be stuck from old
paint. Operate Quicko™ or Sureo™ valve to
release.
6. Replace the inlet valve.*
7. Take sprayer to Authorized Service Center.
1. Replace the spray tip with a new tip.**
2. Clean the suction set screen.
3. Clean or replace the proper lter. Always keep extra
lters on hand.
4. Thin or strain the paint.
5. Replace the inlet valve.*
1. Take sprayer to Authorized Service Center.
1. Take the sprayer to a Authorized Service Center.
1. Check the tip assembly and assemble properly.
2. Replace the seal.**
1. Clean the spray tip or gun lter.
2. Put the tip in the SPRAY position.
1. Increase the pressure.
2. Clean the lters.
3. Tighten the suction tube tting.
4. Replace the spray tip.
5. Thin the paint.
6. Refer to Causes and Solutions for problem C.
Before servicing, always release system pressure by
following Pressure Relief Procedure (page 7).
* Special repair kits with instructions are available for these procedures. Refer to the Maintenance section of this manual for a list
of the kits and their part numbers.
** Additional parts are available for this procedure. Refer to the Accessories (page 47) section of this manual for a list of the parts
and their part numbers.
Daily Maintenance
The only daily maintenance necessary is thorough cleaning and lubricating
after usage. Follow the cleaning and lubricating procedures in this manual.
Extended Maintenance
Some pump parts eventually wear out from use and must be replaced. The
following list indicates the available repair kits for the parts replaced by each kit.
However, pump performance is the only reliable indicator of when to replace
wear parts. Refer to the Troubleshooting section for more information on
when to use these kits.
Kit Part # Description
0516701 Fluid Section Seal Kit (XT250, XT290)
0516700 Fluid Section Seal Kit (XT330)
0516735 Inlet Valve Kit (XT250)
0516727 Inlet Valve Kit (XT290)
0516728 Inlet Valve Kit (XT330)
