Components and Description
Components Tools Needed for Assembly
The shipping carton for your painting system contains the
following:
• Suction tube and return tube
• Pump cleaning adapter
• Spray gun with lter
• Spray tip assembly (see chart on next page)
• 25’ (XT250, XT290) or 50’ (XT330), 1/4” diameter
pressure hose
• Instruction manual
• Two adjustable wrenches
• Extension cord (refer to Important Electrical
Information, page 3).
Controls and Functions
ON/OFF Switch .............................. The ON/OFF switch turns the power to the sprayer on and off (O=OFF, l=ON).
Suction tube ................................... Fluid is drawn through the suction tube into the pump.
Fluid Section .................................. A piston in the uid section moves up and down to create the suction that draws uid through the
suction tube.
Spray Gun ...................................... The spray gun controls the delivery of the uid being pumped. The gun model you have depends
on your sprayer model (refer to Spray Gun/Tip Chart, next page).
Spray Hose ..................................... The spray hose connects the gun to the pump.
Return Tube ................................... Fluid is sent back out through the return tube to the original container when PRIME/SPRAY knob is
in PRIME position.
Pump Cleaning Adapter ................ The adapter allows you to attach a garden hose to the suction tube for easy cleanup (latex
materials only).
PRIME/SPRAY Knob ...................... The PRIME/SPRAY knob directs uid to the spray hose when set to SPRAY or the return tube
when set to PRIME. The arrows on the PRIME/SPRAY knob shows the rotation directions for
PRIME and SPRAY.
The PRIME/SPRAY knob is also used to relieve pressure built up in the spray hose (see Pressure
Relief Procedure, page 7).
PressureTrac™ ............................. The PressureTrac™ regulates the amount of force the pump uses to push the uid.
Quicko™ valve............................. (XT250 only) The Quicko™ valve is designed to keep the inlet valve open and from sticking to
dried materials. The Quicko™ valve is activated manually by the user.
Sureo™ valve............................... (XT290 and XT330 only) The Sureo™ valve is designed to keep the inlet valve open and from
sticking due to dried materials. The Sureo™ valve is activated automatically every time you turn
the ON/OFF switch ON.
Specications
Capacity:
XT250 ...........Up to .25 gallon (0.95 liter) / minute
XT290 ...........Up to .29 gallon (1.1 liters) / minute
XT330 ..........Up to .33 gallon (1.25 liters) / minute
Power source:
XT250 ...........1/2 Hp universal motor
XT290 ...........5/8 Hp universal motor
XT330 ...........3/4 Hp permanent magnet DC motor
Power requirement:
15 amp minimum circuit on 115 VAC, 60 Hz current
Generator power requirement:
8000 Watt
Safety features:
Spray gun trigger lock and pressure diffuser; built-in tip
safety guard; PRIME/SPRAY knob for safe pressure
release.
Capability:
Sprays a variety of paints, primers, stains, preservatives
and other nonabrasive materials, including pesticides and
liquid fertilizers.
This pump should not be used with textured materials,
block ller, or asphalt sealer.
