Titan XT290 - Page 5

5
English
Components and Description
*The pump cleaning
adapter can be clipped
to the spray hose port
Spray Gun Assembly
Lubricating area
Spray hose port
Pail bracket
Inlet filter
*Pump cleaning
adapter
Suction tube
Return tube
Clip
Leg lock (cart
models only)
PRIME/SPRAY
knob
Knob (cart
models only)
Return tube
fitting
Sureflo™
valve
Quickflo™ valve
(XT250 only)
Spray hose
Spray gun (see chart
above for models)
(LX60 shown)
O
l
Spray
guard
Spray tip (see chart
above for models)
Saddle seat**
Washer**
Saddle seat and washer come
pre-assembled inside spray guard
**
This pump is available in a stand model (XT250) and cart models (XT290 shown below, and XT330). All information given for
the stand model applies to the cart models except where indicated.
NOTICE
Some of the graphics in this manual may not exactly match your sprayer and spray gun. All information and instructions
given in this manual applies to all models except where noted.
XT290
XT330
XT-05
LX60
415
517
415
519
Yellow (fine)
XT250 XT-05 415 415 Yellow (fine)
White (medium)
25 feet
25 feet
50 feet
