Congurable Item Range Default Additional information
Min Max
Room Sensor 1 na na %RH
These settings are only available when
Room Sensor1 is enabled in SETUP3
menu.
Room Sensor 1 is setup by default for use
with an %RH sensor.
Room sensor can be congured to also
operate with;
o Air Quality (AQ) Sensor - PPM,
o CO2 Sensor - PPM CO₂,
o Temperature Sensor - °C.
0000 9999
Continuous SPEED 2
Proportional Increase
20
Sensor
Min Point
0V
90
Sensor
Max Point
10V
60
Set Point
Low
70
Set Point
High
Boost SPEED 3
Set point Low Dynamic Dynamic 60% Sensor Min & Max values are setup in
SETUP3 menu
Recommended Default High & Low
Values for sensors
Sensor
Type
Titon
Part №
SP
Low
SP
high
°C TP543 0017 0027
CO₂ PPM TP541 0800 1400
AQ PPM TP540 0800 1400
%RH TP542 0060 0070
Set point High Dynamic Dynamic 70%
Room Sensor 2 na na CO₂
These settings are only available when
Room Sensor2 is enabled in SETUP3
menu.
Room Sensor 2 is setup by default for use
with an CO₂ sensor.
Room sensor can be congured to also
operate with;
o Temperature Sensor - °C.
o Air Quality (AQ) Sensor - PPM,
o Humidity Sensor - %RH
0000 9999
Continuous SPEED 2
Proportional Increase
450
Sensor
Min Point
0V
1850
Sensor
Max Point
10V
800
Set Point
Low
1400
Set Point
High
Boost SPEED 3
