Titon TP534 - Setup3

Congurable Item Range Default Additional information
Min Max
Set point Low Dynamic Dynamic 800PPM Sensor Min & Max values are setup in
SETUP3 menu
Recommended Default High & Low
Values for sensors
Sensor
Type
Titon
Part №
SP
Low
SP
high
°C TP543 0017 0027
CO₂ PPM TP541 0800 1400
AQ PPM TP540 0800 1400
%RH TP542 0060 0070
Set point High Dynamic Dynamic 1400PPM
Internal Humidity Boost On O O
Internal Humidity %RH
Boost FULL
%RH Boost Set point 30% 89% 70% HRV will switch to Boost SPEED 3 when
%RH is greater than set point value.
%RH Boost Overrun
timer
1 min 60 mins 15 mins The timer is engaged when the %RH
has decreased to the %RH set point
less the %RH Boost Hysteresis.
%RH Boost Hysteresis 1% 10% 1%
During falling humidity scenarios the HRV will remain in Boost SPEED 3 until the %RH has decreased to below %RH set point
less %RH Boost Hysteresis and the % RH Boost Overrun timer has elapsed.
When the timer is in operation the hour glass symbol is displayed.
SETUP3
Congurable Item Range Default Additional information
Min Max
SETUP3 pass code na na 3333 Pass code needs to be entered to
congure settings in the SETUP3 menu
Continuous SPEED2 Supply 14% 100% 40%
Extract 14% 100% 40%
Boost SPEED3 Supply 14% 100% 70%
Extract 14% 100% 70%
Setback SPEED1 Supply 14% 100% 18%
Extract 14% 100% 18%
Press and release the + / - key to modify the mantissa (decimal).
Press and hold the + / - key to modify the characteristic (integer)
HRV fan speed will change to reect the displayed setting when the button is released. Changes in fan speed will take time
to be reected as changes to the ventilation system airow rates.
Boost Overrun Kitchen 0 mins 60 mins 15 mins
Wet Room 0 mins 60 mins 15 mins
Boost Overrun timers are set independently for Kitchen and Wet Room inputs.
Boost Overrun timers must be set greater than zero for any momentary switch or the aurastat fan button to trigger boost.
The aurastat's fan button uses the Kitchen Boost Overrun timer. When using latching switches to initiate Boost SPEED 3 the
Overrun timer will start when the latching switch is disengaged.
Boost Delay Timer 0 mins 60 mins 0 mins
If the Boost Delay Timer is set greater than zero momentary switches of the aurastat's fan button will not switch the HRV into
Boost SPEED 3. When using latching switches, if the Boost switch is turned of before the Boost Delay Timer has elapsed the
HRV will not Boost.
18
