Congurable Item Range Default Additional information
Min Max
SPEED4 SUMMERboost® 14% 100% 100% SUMMERboost® is only available
on models with Summer By Pass.
SUMMERboost® is enabled by default.
Press and release the + / - key to modify the mantissa. Press and hold the + / - key to modify the characteristic (integer).
HRV fan speed will change to reect the displayed setting when the button is released. Changes in fan speed will take time
to be reected as changes to the ventilation system airow rates.
Frost set point -2°C 11.5°C 2°C
Press and release the + / - key to modify the mantissa. Press and hold the + / - key to modify the characteristic (integer)
Frost Protection Mode O Reduce O
O = When temperature detected is below Frost set point Frost Protection activates turning o the Supply fan.
Reduce = When temperature detected is below Frost set point Frost Protection activates, progressively reducing the speed of
the Supply fan until the temperature reaches 4°C below Frost set point at which point the Supply fan is stopped.
Room Sensor 1 Enable/
Disable
Enable Disable Disable Activates Setup Room Sensor 1 in SETUP2
menu.
Room Sensor Type %RH Options are;
Temperature Sensor - °C,
CO₂ Sensor - PPM,
Air Quality Sensor - PPM,
Humidity Sensor - %RH.
Settings required for Titon supplied
sensors:
Sensor
Type
Titon
Part №
Min
0V
Max
10V
°C TP543 0000 0040
CO₂ PPM TP541 0450 1850
AQ PPM TP540 0450 1850
%RH TP542 0020 0090
Consult manufactures data sheets for
details.
Sensor Min Point 0V 0 9999 20%
Sensor Max Point 10V 0 9999 90%
0000 9999
Continuous SPEED 2
Proportional Increase
20
Sensor
Min Point
0V
90
Sensor
Max Point
10V
60
Set Point
Low
70
Set Point
High
Boost SPEED 3
