ARTICULATED ARM OPENERS USER MANUAL
14
6. MAINTENANCE
Low Voltage
24V
24V power supply
for great safety
Durability
Solid material apply
with lasting usage
EZ Instal
Easy installation
and user friendly
interface
Silence
Worm gear application
give silence operation
Manual release device
with easy use and
highly protection
Key Release
Conduct the following operations at least every 6 months. If in high intensity of use, shorten the period in between.
Disconnect the power supply:
(1) Clean and lubricate the screws, the pins, and the hinge with grease.
(2) Check the fastening points are properly tightened.
(3) Make the wire connection are in good condition.
Connect the power supply:
(1) Check the power adjustments.
(2) Check the function of the manual release.
(3) Check the function of photocells or other safety devise.
B
TECHNICAL FEATURE:
Model
Motor
Gear type
Nominal thrust
Maximum Gate Weight
Maximum Gate Length
Operating Temperature
Dimension
Weight
PAPILLON 250
24Vdc motor
Electromechanical worm gear
1200N
250 kg per leaf
2.5 meters per leaf
-20
o
C~+50
o
C
256 x 187 x 267mm
6 kg
Model
Main power supply
Back-up battery
Receiver board
Installation
Operating Temperature
Dimension
CB19
230Vac/110Vac, 50Hz/60Hz
2pcs of batteries for emergency operation, 1.2A each
433.92MHz; 200 transmitters memory
Wall mounted vertically
-20
o
C~+50
o
C
275mm x 195mm x 102mm
