13
FL
SE Terminal Function
FL-0
SE Terminal Function OFF
(Default setting)
FL-1
When gates closing , it will
stop when SE terminal is
triggered.
FL-2
When gates closing , it will
reverse for 2 sec when SE
terminal is triggered.
FL-3
When gates closing , it
will reverse to fully open
position when SE terminal is
triggered.
Condominium Mode
Step by step
button
Ped button PH2 PH1
Stop in the
middle
Open till fully
open and reload
auto-closing time
No effect
Auto-closing
countdown
When Ph2 is
triggered,auto-closing
stops until the obstacle is
removed.
When Ph1 is
triggered,auto-closing
stops until the obstacle is
removed.
Gate fully open
reload auto
closing time
No effect
Auto-closing
countdown
When Ph2 is
triggered,auto-closing
stops until the obstacle is
removed.
When Ph1 is
triggered,auto-closing
stops until the obstacle is
removed.
Opening phase No effect No effect No effect No effect
Gate fully close
Open the gate
until it's fully
open and start
auto-closing
countdown
Opened to
50% or 100%
of the
pedestrian
mode, the
automatic
gate closing
countdown
will start.
1.When Ph2 is triggered, it
can accept any opening
signal (including open,
stop, close ,stop, and
pedestrian mode keys),
but the gate can only be
opened.
2.After opening to the
position, the automatic
gate closing timer stops
countdown, and after
the obstacle is removed,
the automatic gate
closing timer restarts.
1.When Ph1 is triggered, it
can accept any opening
signal (including open,
stop, close ,stop, and
pedestrian mode keys),
but the gate can only
be opened.
2.After opening to the
position, the automatic
gate closing timer stops
countdown, and after
the obstacle is removed,
the automatic gate
closing timer restarts.
Closing phase
Open the gate
until it's fully
open and start\
auto-closing
ountdown
No effect
When Ph2 is
triggered,reverse
to the fully open
position. Auto-closing
stops until the
obstacle is removed.
When Ph1 is
triggered,reverse to the
fully open position. Auto
closing stops until the
obstacle is removed.
Trigger
Device
Status
of Gate
