Toa KD-1 User Manual

Specifications
INPUT SPECIFICATIONS
Input
CHANNEL INPUT
CH1~CH4
MIC CH1
AUX IN
EFF RET
OUTPUT SPECIFICATIONS
Actual
Load
Impedance
For Use
With
Nominal
Input Level
Nominal
-30dB (24mV)
-60dB (0.78mV)
-20dB (78mV)
-20dB (78mV)
MAX. Before Clip
0dB (0.775V)
-30dB (24mV)
+10dB (2.45V)
+ 10dB (2.45V)
0dB is referenced to 0.775V RMS.
Connector
PHONE JACK
RCA PIN JACK
XLR-3-31 TYPE
PHONE JACK
PHONE JACK
Output
REG OUT
EFF SEND
HEAD PHONE
EXT. SP
Actual
Source
Impedance
For Use
With
Nominal
Output Level
Nominal
-10dB (245mV)
-10dB (245mV)
+4dB (1.23V)
50W/8
MAX. Before Clip
+20dB (7.75V)
+20dB (7.75V)
+20dB (7.75V)
Connector
RCA PIN JACK
PHONE JACK
STEREO PHONE
JACK
PHONE JACK
0dB is referenced to 0.775V RMS
Specifications are subject to change without notice.
Stereo phone jack is wired:
Tip=Left, Ring=Right, Sleave=Common.
The XLR type connector is electronically balanced.
The XLR type connector is wired as follows
PinNo.1-Ground
Pin No.2-Cold (Low)
Pin No.3-Hot (High)
Appearance
