16
Step 6. Install the measuring microphone.
It is recommended to install the microphone as shown below as a guide.
45°
[Microphone setting example]
[Microphone setting example]
Location of the microphone: About the center of the room
Height of the microphone: At the listening position
Angle of the microphone: 45 º up
Location of the microphone: About the center of the room
(See the figure below.)
Direction of the microphone: Point to the speaker. (See the figure below.)
School room: Point to a platform.
Gymnasium and multipurpose auditorium: Point to the center of the stage.
Conference room: Point to the chairperson.
