SPECIFICATIONS 13
2
ENOM00301-0
Remark: Specifications subject to change without notice.
*1 With propeller, with battery cable.
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
MF, EF, EFT
Item MODEL
15D/20D
MF
EF
EFT
Overall Length mm (in) 1055 (41.5)
Overall Width mm (in) 365 (14.4)
Overall Height S·L·UL mm (in) 1085 (42.7) 1325 (48.6) 1362 (53.6)
Transom Height S·L·UL mm (in) 413 (16.3) 562 (22.1) 669 (27.1)
Weight*1
S kg (lb) 52 (115) 55.5 (122) 62.5 (138)
L kg (lb) 53.5 (118) 57.0 (126) 64.0 (141)
UL kg (lb) 55 (121) 58.5 (129) 65.5 (144)
Output kW (ps) 15D : 11.0 (15) 20D : 14.7 (20)
Max. Operating Range rpm
15D: 5000-6000
20D: 5400-6100
Idle Speed in Forward Gear
rpm 900
Idle Speed in Neutral Gear rpm 950
Engine Type 4-Stroke
Number of Cylinder 2
Bore × Stroke mm (in) 61 × 60 (2.40 × 2.36)
Piston Displacement mL (Cu in) 351 (21.42)
Exhaust System Through hub exhaust
Cooling System Water cooling
Engine Lubrication Trochoid pump
Starting System Manual Electric starter motor*
Ignition System Flywheel Magneto C.D. ignition
Spark Plug NGK DCPR6E
Trim Posi tion 6
Engine Oil mL (fl.oz.) API SF, SG, SH, SJ, SL 10W-30, Approx. 1000 (33.8)
Gear Oil mL (fl.oz.) Genuine Gear Oil or API GL5, SAE #80-90, Approx. 370 (12.5)
Fuel
Unleaded regular gasoline : Pump posted
87 Octane (research octane rating of 91)
Fuel Tank Capacity L (US gal) 12 (3.17)
Gear Reduction Ratio 2.15 (13 : 28)
Emission Control System EM (Engine modification)
Operator Sound Pressure
(ICOMIA 39/94) dB (A)
83.9
Hand Vibration Level
(ICOMIA 38/94) m/sec2
2.5
MFS15-20D_EUR_EN_141119N.book 13 ページ ２０１４年１２月２３日 火曜日 午後６時４１分
