SPECIFICATIONS 13
2
EENOM00401-0
*1:Equipped only for SP model, the other models OPTION.
*2:In case of dual fuel tank system. Able to use together with 12 L separate tank.
Remark: Specifications subject to change without notice.
*3 With propeller, with battery cable.
Tohatsu outboard is power rated in accordance with ISO8665 (propeller shaft output).
MF
Item MODEL
4C(D) 5C(D) 6C(D)
(Dual Tank)
5C(S) 6C(S)
(Separate
Tank)
6C(S) SP
(Separate
Tank)
Overall Length mm (in) 783 (30.8)
Overall Width mm (in) 343 (13.5)
Overall Height S·L·UL mm (in)
Except for USA and Canada model
1053 (41.5) 1180 (46.5) 1307 (51.5)
1039 (40.9)
1166 (45.9)
1293 (50.9)
For USA and Canada model
1067 (42.0) 1194 (47.0) 1321 (52.0)
Transom Height S·L·UL mm (in) 435 (17.1) 562 (22.1) 689 (27.1)
Weight *3
S kg (lb) 26.1 (57.5) 25.6 (56.4)
L kg (lb) 26.6 (58.6) 26.1 (57.5)
UL kg (lb) 27.1 (59.8) 26.6 (58.6)
Output kW (ps) 4C : 2.9 (4) 5C : 3.7 (5) 6C : 4.4 (6)
Max. Operating Range
min
-1
(rpm)
4C & 5C : 4500–5500 6C : 5000–6000
Idle Speed in Forward
Gear
min
-1
(rpm)
1100
Idle Speed in Neutral Gear
min
-1
(rpm)
1300
Engine Type 4-Stroke
Number of Cylinder 1
Bore × Stroke mm (in) 59 × 45 (2.32 × 1.77)
Piston Displacement
cm
3
(Cu in) 123 (7.5)
Exhaust System Through hub exhaust
Cooling System Water cooling
Engine Lubrication Trochoid pump
Starting System Manual starter
Ignition System Ignitor
Spark Plug NGK DCPR6E
Alternator 12V 60W 5A (Max.) *1
Trim Position 6
Engine Oil mL (fl.oz.) API SF, SG, SH or SJ, SAE 10W-30/40, Approx. 450 (15.2)
Gear Oil mL (fl.oz.) Genuine Gear Oil or API GL5, SAE #80-90, Approx. 195 (6.6S)
Fuel
Unleaded Regular Gasoline : R+M/2: 87 or higher RON: 91 or higher
Fuel Tank Capacity L (US gal) 1.15 (0.30) Integral *2 12 (3.17) Separate
Gear Reduction Ratio 2.15 (13 : 28)
Emission Control System EM (Engine modification)
Operator Sound Pressure
(ICOMIA 39/94) dB (A)
81.6
Hand Vibration Level
(ICOMIA 38/94) m/sec2
7.2
