72
13
PROPELLER TABLE
ENOM00438-0
Use a genuine propeller.
A propeller must be selected so that the engine rpm measured at wide open throttle
while cruising is within the recommended range.
4: 4500–5500 min
-1
(rpm)
5: 4500–5500 min
-1
(rpm)
6: 5000–6000 min
-1
(rpm)
S: Short shaft
L: Long shaft
UL: Extra long shaft
*: SP model
Propeller
Mark
Propeller Size (Diameter ×
pitch)
Standard propeller on the model
inch mm 4 5 6
Light boats 9 7.9 × 9.0 200 × 229
8 7.8 × 8.0 198 × 203 S, L S, L
7 7.8 × 7.0 198 × 178 S, L
Heavy boats 6 7.9 × 6.0 200 × 152 *UL
