24/35
xvi. Baud rate (Default: 9600bps)
Select the baud rate from 2400, 4800, 9600 or 19200 bps. Match it with your PC
setting.
Select the baud rate using upper or down arrow keys. Press “MEM” key to save setting
and go to next. Press “MD” key to skip setting and go to next. Press “C” key to go back
to RUN mode (measurement mode).
xvii. Data length (Default: 8bit)
Select the data length from 7 bit or 8 bit. Set to 8 bit when use #584 USB connection
cable.
Select the data length upper or down arrow keys. Press “MEM” key to save setting and
go to next. Press “MD” key to skip setting and go to next. Press “C” key to go back to
RUN mode (measurement mode).
