Front Panel User Guide Page 12
2.4 Ranging and Test Menu: Test Transit Band
This command will simulate a transit band preemption event on a channel.
1. Select the Ranging and Test menu item. Issue a
selection press on the pushbutton twice. The
front panel indicates that the top level menu item
for ranging and test has been selected.
2. Utilize the Ranging and Test submenu
commands. Issue a utilize press on the
pushbutton (> 2 s). Release the button after the
LED changes to amber. The front panel indicates
that the submenu item for emergency band test
has been selected.
4
5
3
2
6
1
Select
LED Off
LED Green
LED Amber
LED Red
Test/Range Menu:
Top Level
4
5
3
2
6
1
Select
LED Off
LED Green
LED Amber
LED Red
Test/Range Menu:
Test Emergency Band
Submenu
