Front Panel User Guide Page 15
3 Full Command Menu – Reset System to Default Configuration
To reset the system to the default configuration from within the full command menu, press and hold the
pushbutton for at least 12 seconds or until the front panel LEDs begin to display a pattern. When the
command is issued, the front panel LEDs will display a pattern indicating the process of setting system
defaults has started.
Note: The heartbeat LED will pulse amber during the process of resetting the system to the default
configuration. When the heartbeat LED returns to a green pulsing, the default operations are complete.
4 Full Command Menu – Operation Reference
A quick reference is provided for the full menu operations. The table represents the actions performed
on the pushbutton to achieve the desired operations. In the table, the symbols are defined as follows:
S – Selection Press
o A pushbutton press held for less than 2 seconds
A brief push and release. LED changes upon release
U – Utilize Press
o A pushbutton press held for 2 seconds
Wait for LED to change state, which occurs in 2 seconds
A – Activation press
o A pushbutton press held for 4 seconds
Wait for LED to change state, which occurs in 4 seconds
CS – Channel select
o A series of selection presses (S) used to select the channel on which to apply the
command
In the table, it is assumed that all pushbutton actions begin with the menu system idle with the initial
select button press resulting in the channel 1 LED turning green.
Disable preemption on a channel
Disable transit on a channel
S -> U -> S -> U -> CS -> A
Issue an emergency band test
S -> S -> U -> U -> CS -> A
Issue a transit band test
S -> S -> U -> S -> U -> CS -> A
S -> S -> U -> S -> S -> U -> CS -> A
Only applies when ranging is armed
Reset system to default configuration
Hold pushbutton at least 12 seconds
Table 1: Front Panel Quick Reference
Note: To ensure the menu system is in the idle state, allow 30 seconds of inactivity on the pushbutton
