TomTom RIDER 2nd Edition User Manual

15
•
•
•
•
•
•
Attach this mount only to a part of your motorcycle that is strong enough to
hold the mount, the Holder and your RIDER.
Think carefully about where you want to attach the Adhesive Mount. Clean the
position you have chosen thoroughly and make sure that you remove any
grease or dirt.
To use this mount, follow these steps:
1. Attach the adhesive pad to the Adhesive Mount.
2. Press and hold the Adhesive Mount in the position you have chosen.
3. Screw the Holder to the Adhesive Mount using four of the small screws
included with the mounting kit.
You can now place your TomTom RIDER in the Holder. See this
section:Placing your TomTom RIDER in the Holder on page 15
Placing your TomTom RIDER in the Holder
1. Open the Holder and place the bottom edge of your TomTom RIDER into
the Holder first.
Make sure that the two teeth on the bottom of the Holder meet the two
connections on your RIDER. If your RIDER is not placed in the Holder
correctly, it may fall out while you are driving.
2. Push your RIDER firmly into place.
Note: It is very difficult to remove the Adhesive Mount.

TomTom RIDER 2nd Edition Specifications

General

Marine (chartplotters, sounders)	No
Map view options	2D/3D
Form factor	Fixed
Channels quantity	20 channels
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
Internal memory	32 MB
Power requirements	12V
Processor frequency	380 MHz
USB 2.0 ports quantity	1
Battery life (max)	5 h
Operating temperature (T-T)	-10 - 55 °C

Weight and Dimensions

Depth	96.2 mm
Width	113.2 mm
Height	52.9 mm
Weight	310 g
