Reference 1 Wiring Definition
X axis pulse positive output
X axis pulse negative output
X axis direction positive output
X axis direction negative output
Y axis pulse positive output
Y axis pulse negative output
Y axis direction positive output
Y axis direction negative output
Z axis pulse positive output
Z axis pulse negative output
Z axis direction positive output
Z axis direction negative output
C axis pulse positive output
C axis pulse negative output
C axis direction positive output
C axis direction negative output
Output 01-08,Connect to power 24V+ through Relay
or solenoid valve
Connect to power 24V- through machine or switch
Used to make special machine controller (This
controller do not support encoder unless customer
specially said they need it)
Connect to I/O extension connection
