Topcon ES-62 - Page 191

19-15
19 TOP FIELD MODE
8 Pressing {F2} (SD) key will switch the distance
display to the SD display.
{F2}
9 Pressing {F3} (NEZ) key will switch to the
coordinate display.
{F3}
10 Pressing {F3} (A/D) key will switch to the
previously measured angle/measured distance
display.
{F3}
11 Pressing {F4} (REC) key will record the data.
 Data to be recorded are recalculated from the
currently displayed angle and horizontal distance
(angle offset function).
To record the coordinate data of the collimate
point, record (REC) them without moving the angle
after measurement (MSR).
{F4}
*1) To change the reflector height, select {F2} (HR) key to switch to the screen for reflector height input.
*2) To edit a coordinate point and its description, select {F2} (EDIT) key to return to the editing mode.
VA: 60°00'00"
HA: 120°00'00"
HD: 11.547 m
MSR HD NEZ REC
N : -5.000 m
E : 8.660 m
Z : 5.774 m
MSR HD NEZ REC
VA: 60°00'00"
HA: 120°00'00"
HD: 11.547 m
MSR HD NEZ REC
PT#: [P02 ]
DESC: [POINT ]
HT ROD: 1.500 m
FAST EDIT HR MSR
PT#: [P01 ]
DESC: [POINT ]
HT ROD: 1.500 m
HR ALP CLR
ENTER TARGET HT
HT OF ROD
=1.500_ m
CLR
PT#: [P01 ]
DESC: [POINT ]
HT ROD: 1.500 m
FAST EDIT HR MSR
PT#: [P01_ ]
DESC: [POINT ]
HT ROD: 1.500 m
HR ALP CLR
{F2}
{F2}
