6-15
6 SPECIAL MODE (Menu Mode)
7 Collimate prism P1 (Origin) and press {F1}
(MEAS) key.
Measuring starts. *1)
Input display of reflector B(P2) height will be
shown.
Collimate
P1
{F1}
8 Enter reflector B(P2) height.
Enter R. HT
{F4}
9 Collimate prism B (P2) (Origin) and press the {F1}
(MEAS) key.
Measuring starts. *1)
The coordinate data and the direction angle of the
instrument are calculated and restored.
The result (The distance between A and B) will be
displayed.
dHD: Horizontal distance
dVD:Vertical distance
dSD:Slope distance *2),3)
Collimate
P2
{F1}
10 Press {F1} (NEZ) key to measure other points.
11 Collimate a prism and press {F1} (MEAS) key.
Coordinate measurement starts. *4)
The result will be shown. *5)
{F1}
Collimate P
{F1}
*1) Measurement is Fine N-times measurement mode.
*2) To show dSD, press {F4} (P
↓ ) key.
*3) To show the new occupied data, press {F2} (S.CO) key.
*4) Measurement is Fine N-times measurement mode.
*5) To return to previous mode, press the {ESC} key.
POINT TO LINE
MEAS.P1
HD*[n] << m
>Measuring...
REFLECTOR HEIGHT
INPUT
R.HT= 0.000 m
--- --- [CLR] [ENT]
POINT TO LINE
MEAS.P2
HD: m
MEAS ––– NP/P –––
POINT TO LINE
MEAS.P2
HD*[n] << m
>Measuring...
DIST. (P1-P2) 1/2
dHD: 10.000 m
dVD: 0.000 m
NEZ S.CO ––– P
↓
N: 0.000 m
E: 0.000 m
Z: 0.000 m
MEAS R.HT NP/P –––
>Measuring...
N: 3.456 m
E: 5.432 m
Z: 0.000 m
MEAS R.HT NP/P –––
