Ver 1.1, 30 August 2018 2
h. Under the Config: Survey Settings window, enter the following before tapping the
checkmark icon near the top-right:
Measurement Type: HA/VA/SD
Target Type: Prism
EDM Mode: Coarse
g. Tap the accept/home screen icon near the top-right.
9. Establish default measurement units:
a. Tap Configure icon.
b. Tap Units icon.
c. Under the Distance tab, enter the following:
Distance unit: US Feet
Distance precision: 0.123
Area unit: Square USFeet
Volume unit: Cubic USFeet
d. Under the Angle tab, enter the following:
Meas angle unit: DD.ddddd°
Meas angle precision: 0.123°
Calc angle unit: DD.ddddd°
Calc angle precision: 0.123°
e. Under the Coordinate tab, enter the following:
Norting/Easting precision: 0.123
Lat/Lon units: DD°MM’SS.s”
Lat/Lon precision: 0°00’00.123”
Height precision: 0.123
f. Under the Other tab, enter the following:
Temperature unit: Fahrenheit (°F)
Pressure unit: inHg
i. Tap the accept/home screen icon near the top-right.
10. Establish default display settings:
a. Tap Configure icon.
b. Tap Display icon.
c. Under the Display window, enter the following:
Coord Type: Ground
Plane Coord Order: Northing,Easting,Height
Geod. Az. Origin: North
Direction: Azimuth
Display Slope As: Percentage (%)
Station Prefix: Sta.
CL Position: 12+34.000
d. Tap the accept/home screen icon near the top-right.
