1 NOMENCLATURE AND FUNCTIONS

1.1 Nomenclature

Laser pointer

Point guide

Objective lens

Display unit

Handgrip locking screw

Instrument

center mark

Optical plummet

telescope

Circular level

Tribrach fixing lever

Base

Adjustment screw

for circular level

Leveling screw

(Only for GPT-3002/

3003/3005)

Handgrip

(Optical plummet

telescope type only)

Laser aperture
