16-3
16 SELECTING MODE
*LANGUAGE selection is different in different countries.
16.2 How to Set Selecting Mode
<Example> : Setting unit in hPa, °F, NEZ MEMORY:ON
ACK MODE STANDARD /
OMITTED
Set the procedure of the communication with
external device.
STANDARD:Normal procedure
OMITTED:Even though the [ACK] is omitted
from the external device, the data is
not sent again.
GRID
FACTOR
USE G.F. /
DON’T USE
Select using GRID FACTOR in calculation of
measurement data.
CUT & FILL STANDARD /
CUT&FILL
In the layout mode, CUT & FILL can be
displayed instead of dZ.
ECHO BACK ON / OFF It is possible to output the data of echo back
type.
CONTRAST
MENU
ON / OFF When the instrument is turned ON, it is possible
to display the screen which you can adjust
contrast of the display and confirm the prism
constant (PSM) and atmospheric correction
value (PPM).
Operating procedure Operation Display
1
While pressing [F2] key, turn power ON.
[F2]
+
Power ON
2
Press [F1](UNIT SET ) key.
[F1]
3
Press [F1](TEMP. & PRES.) key.
[F1]
4
Press [F2](°F) key, and press
[F4](ENTER) key.
[F2]
[F4]
5
Press [F1](hPa) key, and press [F4] (ENTER) key.
Returns to unit set menu.
[F1]
[F4]
6
Press [ESC] key.
Returns to PARAMETERS 2 menu.
[ESC]
PARAMETERS 2
F1:UNIT SET
F2:MODE SET
F3:OTHERS SET
UNIT SET 1/2
F1:TEMP. & PRES.
F2:ANGLE
F3:DISTANCE P
TEMP. & PRES. UNIT
TEMP. = °C
PRES. = mmHg
°C °F ––– ENTER
TEMP. & PRES. UNIT
TEMP. = °F
PRES. = mmHg
hPa mmHg inHg ENTER
UNIT SET 1/2
F1:TEMP. & PRES.
F2:ANGLE
F3:DISTANCE
PARAMETERS 2
F1:UNIT SET
F2:MODE SET
F3:OTHERS SET
