Topcon HiPer VR Quick Reference Card

STATUS LED
Green Blink One blink per tracked GPS satellite.
Yellow Blink One blink per tracked GLONASS satellite.
Cyan Blink One blink per tracked Galileo satellite.
Magenta Blink One blink per tracked BeiDou satellite.
Blue Blink One blink per tracked QZSS satellite.
White Blink One blink per tracked L-band Satellite.
Red Blink
One blink when there are no tracked satellites or
solutions. Two blinks per second when the receiver is in
exception mode. Otherwise, the LED is o󰀨.
Red Solid
+ Green Solid
+ Yellow Solid
OAF is expired.
RECORDING (REC) LED
LED blink mode switch enabled
Green Blink File logging is in progress.
Red Solid
File logging is in progress. The Static mode is the current
post-processing mode.
Occupation mode switch enabled
Green Blink
File logging is in progress. Static mode is the current post-
processing mode.
Yellow Blink
File logging is in progress. Kinematic mode is the current
post-processing mode.
Red Solid
File logging problem. No free memory, or hardware
problem with data recording.
LED is o󰀨 when le is not logging data.
BLUETOOTH LED
Blue Blink Bluetooth is on and waiting for a connection.
Blue Solid A single Bluetooth connection has been established.
Blue Solid +
Blue Blink *N
every 10
seconds
Multiple (N) valid Bluetooth connections have been
established.

Topcon HiPer VR Specifications

General

Battery Life	Up to 10 hours
Ingress Protection	IP67
Internal Memory	8 GB
Signal Tracking	GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS
Static Accuracy Horizontal	3 mm + 0.1 ppm
Static Accuracy Vertical	5 mm + 0.5 ppm
Communication	Bluetooth, Wi-Fi
Operating Temperature	-40°C to +65°C
Update Rate	20 Hz
