28
OPERATION PROCEDURE
OPERATING THE MICROSCOPE UNIT
Turn the magnification selector to set a magnification value against the magnification index
mark.
SL-D7
SL-D8Z
For the overall magnification in conjunction with magnification marks of the magnifi-
cation selector handle, see page 37.
Magnification selector
handle
Magnification index mark
Magnification index mark
Magnification selector handle
