1.1. Parts list
2
Part Number Description
A3453 CABLE, AgCam ext 20 foot x 2
1004051-01 PSWD-CG, Camera Unlock Code x 1
AGA5107 MANUAL, Camera Monitor x 1
Y216 CABLE TIE, 160 mm x 2.6 mm black x 20
AGW289 WARRANTY CARD, AG Universal x 1
X35 and X25 consoles
1019150-1 KIT, X35/X25 AgCam 1 camera with 20ft cable
Part Number Description
1016437-01 HRNS AGCAM ADAPTER x 1
1004681-01 CAMERA, AgCam PAL 92 degree x 1
A3453 CABLE, AgCam ext 20 foot x 1
