Tools Needed:
·Power Drill
·Tape Measure
·Open End Wrenches — 14# &17# or Adjustable Wrenches
·Wire Strippers
·C-Clamps — small, medium, and large
·Level
·Phillips Screwdriver
·An extra person will be helpful
Technical Specifications & Features
Specifications
Input:
110V~120V/60Hz or 220~240V/50Hz
Motor voltage:
24VDC
Motor Power:
40W
Motor Current:
2A
Actuator speed:
30mm/s
Max. actuator travel:
380mm
Ambient Temperature:
-20℃~ +50℃ (0°F to 120°F)
Protection class:
IP44
Gate Capacity of HJ4022 for Each Actuator and HJ4021
200 kg (440 lbs)
√
NR
NR
NR
150 kg (330 lbs)
√
√
NR
NR
100 kg (220 lbs)
√
√
√
NR
50 kg (110 lbs)
√
√
√
√
1.2-1.8 m (4-6’)
2.4 m (8’)
3 m (10’)
3.6 m (12’)
These specifications are subject to change without notice.
Gate Length
NOTE: “NR" indicates this size and weight combination is NOT recommended for one arm actuator.
NOTE: Ball bearing hinges should be used on all gates weighing over 140kg (300 lbs).
