Single Swing Gate Opener

User’s Manual

Model:

TOPENS Website

www.topens.com

Email: support@topens.com

VER 21c

A3/A5/A8

A3S/A5S/A8S

★ Please read and follow all warnings, precautions and instructions before

installation and use.

★

A 24V 12Ah battery (NOT INCLUDED, 2pcs 12V batteries connected in series may

function as 24V), OR the UPS01 AC-DC Power Supply (NOT INCLUDED) is

REQUIRED to power up this gate opener. The adapter included in the package is

ONLY used to charge the battery.

★

Never connect the solar panel to the control board directly to charge the battery.

★ Periodic checks of the opener are required to ensure safe operation.

★ Save this manual.

C030449

Questions and Answers:

F
Felicia JonesAug 1, 2025
How to fix Topens EK700M Gate Opener that opens but doesn't close?
- S
  Shelley Heath MDAug 1, 2025
  If your Topens gate opener opens but doesn't close, first check if the connection of the photocell beam is not blocked, assuming a photocell is being used. Also, the closed limit switch might be broken. To check it, remove the BLUE, GREEN, and YELLOW wires of the arm from the control board and use a jumper wire to short the ULT, COM, and DLT terminals; if the arm runs normally, the limit switch is faulty. If neither of these resolves the issue, the control board itself could be faulty and may need replacing.
A
Andrew NicholsAug 5, 2025
Why Topens EK700M Gate Opener automatically opens, but does not automatically close?
- A
  Angela CurtisAug 6, 2025
  If your Topens gate opener automatically opens but doesn't automatically close, the setting of DIP switch #1 might be incorrect. Ensure the DIP switch is set correctly according to the push/pull to opener installation of the gate opener.
S
scottmillerAug 10, 2025
Why Topens EK700M Gate Opener does not respond to the remote control?
- E
  Edward FisherAug 11, 2025
  If your Topens gate opener isn't responding to the remote, there are several potential reasons. First, ensure the remote has been properly programmed to the control board. If it has, the remote's battery may be dead; try replacing it. Another possibility is a broken limit switch. To test this, remove the BLUE, GREEN, and YELLOW wires from the control board, then use a jumper wire to short the ULT, COM, and DLT terminals. If the arm now runs normally, the limit switch is faulty. Lastly, the control board itself could be faulty and need replacement.
D
Denise ScottAug 14, 2025
What to do if Topens Gate Opener moves a little and then stops?
- V
  Victor BeckAug 15, 2025
  If your Topens gate moves a little and then reverses or stops, it could be that the selected force is too small to move the gate. Try turning the Potentiometer clockwise to increase the force. Also, disconnect the gate from the gate operator and check that the gate slides freely without any binding.
J
jessicahernandezAug 19, 2025
What to do if Topens Gate Opener Power LED does not turn on?
- M
  Monica HuntAug 19, 2025
  If the Power LED on your Topens gate opener does not turn on, ensure the connection between the battery and control board is correct and fastened. Check the fuse in the control board and replace it if it's burnt out. If the problem persists, the control board itself might be faulty and need replacement.
B
bradley41Aug 22, 2025
Why my Topens Gate Opener's Power LED flashes rapidly and doesn't run?
- C
  Christine BauerAug 23, 2025
  If the Power LED on your Topens gate opener flashes rapidly and the opener doesn't run, it's likely due to an over-discharged battery. Check the battery voltage; it should be above 22V for the gate opener to function normally.
N
Nancy RobertsonAug 27, 2025
How to troubleshoot Topens Gate Opener when only the CODE LED is slightly on?
- J
  John WarrenAug 27, 2025
  If your Topens gate opener isn't running and only the CODE LED is slightly on, the batteries may not be connected to the control board, or the wire connection of the batteries is loosened. Note that two 12V batteries are required to power up the gate opener. The adapter included in the package is only for charging the batteries.

Topens EK700M Specifications

General

Type	Sliding Gate Opener
Motor Type	DC Motor
Safety Features	Auto-stop, Obstacle Detection
Weather Resistance	IP44
Protection Level	IP44
Battery Backup	No
Max Gate Length	40 ft (12 m)
Control Method	Remote Control
Operating Temperature	-4°F to 122°F
Remote Control Range	30m
Power Supply	AC 110V/60Hz

Summary

CONTACT US

Safety Installation Information

CHECK YOUR GATE

A3 Parts List

Hardware

Lists all hardware components included in the A3 parts kit for assembly.

A5/A8 Parts List

Extra Parts for A3/5/8 S

Accessories Parts (Included in some models, refers to the actual package)

Optional Accessories Parts List (Available at TOPENS Store)

Replacement Parts

Tools Needed

Technical Specifications & Features

Gate Capacity of A3(S)

Details the maximum gate weight and length supported by the A3(S) model.

Gate Capacity of A5(S)

Details the maximum gate weight and length supported by the A5(S) model.

Gate Capacity of A8(S)

Details the maximum gate weight and length supported by the A8(S) model.

Installation Overview

Pull-to-Open Gate

Overview of the installation for pull-to-open gate configuration.

Preparation for Installation

Install the Opener on the Gate – for Pull to Open

Step-by-step guide for installing the opener on the gate for pull-to-open.

Install the Opener on the Gate – for Push to Open

Step-by-step guide for installing the opener on the gate for push-to-open.

Mounting of the Control Box

Connection of the Power Supply

Use the batteries as the power source and only use the adapter to charge the batteries

Instructions for powering the unit using batteries and charging them with the adapter.

Use the adapter & solar panel to charge the batteries at the same time

Instructions for charging batteries using both adapter and solar panel simultaneously.

Use the solar panel to charge the batteries

Instructions for charging batteries exclusively with the solar panel.

Use the DPS180-U AC-DC power supply as the power source if AC electricity is accessible and stable

Guidance on using the AC-DC power supply as the primary power source.

Use the UPS01 uninterrupted power supply as the power source

Instructions for powering the unit using the UPS01 uninterrupted power supply.

Connection of the Control Board

Actuator

Wiring instructions for connecting the actuator to the control board.

Battery OR AC-DC power supply (Required but not included)

Connecting battery or AC-DC power supply as the main power source.

Adapter (Only used to charge the batteries)

Using the included adapter solely for charging the batteries.

Warning Light (Included in some models, refers to the actual package)

Wiring instructions for the optional warning light accessory.

Photocell Beam System (PBS) (Included in some models, refers to the actual package)

Wiring instructions for the optional photocell beam system.

Push Button (optional)

Wiring instructions for the optional push button.

Electric Lock (optional)

Wiring instructions for connecting an optional electric lock.

Exit Wand (optional)

Wiring instructions for the optional exit wand.

Wired Keypad (24VDC) (optional)

Wiring instructions for the optional wired keypad.

External receiver (optional)

Wiring instructions for the optional external receiver.

How to Program the Remote to the Opener

How to Erase All the Remote Codes

How to Use the Remote to Operate Your Gate Opener

Wireless Keypad Programming

Adjusting the Limit Switch

For Pull-to-Open Installation, adjust the limit switch B to determine the closed position

Adjusting limit switch B for the closed position in pull-to-open setups.

For Push-to-Open Installation, adjust the limit switch B to determine the open position

Adjusting limit switch B for the open position in push-to-open setups.

Setting of the Control Board

DIP Switches

Configuration of DIP switches for various gate opener functions.

Potentiometers

Explanation of potentiometers for adjusting force, auto-close, and soft stop.

Maintenance

Trouble Shooting
