OPERATION MANUAL
15
MP5909/6916/8916
1.3 REAR LAYOUT
AC power inlet
115/230 VAC switch
Verify that the voltage is
set correctly for user
location
!
WARNIN
G
LPT1 printer port
Pan/Tilt port 1,2
LAN
Video output
TV out 1,2
Sensor Digital out
Audio output
Camera in
Mouse
Keyboard
USB port
TOPS 8916
Audio input
Camera output
TOPS 5916
TOPS 6916
Audio input
