OPERATION MANUAL
18
Screen Information Channel Information
②
③
①
① Camera Name
② Recording Status
NOR – Normal Recording
MOT – Motion Recording
SEN – Sensor Recording
MOT+SEN – Motion + Sensor
A – Audio Recording
③ Camera Image
Camera View Layout
①1 CH
②4 CH
③9 CH
④ 16 CH
⑤1 Main + 7 Sub CH
⑥ 1 Main + 12 Sub CH
⑦2 Main + 8 Sub CH
⑧3 Main + 4 Sub CH
⑨Rotation
⑩ User Selection
⑪Pop UP ON/OFF
⑫ Full Screen
① Camera Group
② Camera No.1
③ Camera Name
④ Camera Resolution
⑤ Camera Protocol
⑥ Sensor Group
⑦ D/O Group (Alarm Out)
⑧ Audio Group
⑨ External Monitor
NOTE:
Sub menu is available when right mouse
click each CH like “External Monitor” or
“ON/ OFF”
②
⑪
⑧
⑫
①
③④
⑦
⑩
⑤
⑨
⑥
⑨
①
②
③
④
⑤
⑥
⑦
⑧
