3.1 SEARCH
① Camera Name
② Recorded Status
③ Playback Image
④ Recorded Time
Main Mode Search Screen
① Search Mode
② Search Screen
③ Camera Information
④ Panorama Search Information
⑤ Camera Layout
⑥ Map & Thumbnail View
User Selection
① Click “USER SELECTION” button
② Drag a cam from “CAMERA
INFORMATION” and drop it on the
“SEARCH SCREEN”
Note:
The search layout will be changeable.
The below is the example of “USER
SELECTION”.
①
③
④
②
Camera Layout
① User Layout Name
② Save User Layout
③ Delete User Layout
④1CH
⑤4CH
⑥9CH
⑦16CH
⑧ User Selection
⑦
①
②
④
⑤
⑥
③
⑧
Cam1. Cam2.
Cam3. Cam4.
Cam2. Cam1.
Cam4. Cam3.
①
③
⑤
⑥
④
②
