User manual of tracker MT01
-
24
-
A=1, enable position report function to
get position SMS by Calling MT01
I=0, disable power failure alert
I=1, enable power failure alert
The functions of BCDEFGHJ are
remained for furthur use.
### is the ending character.
Set Geo-fence alarm
017 command is for
alarm when tracker
moves out the preset
scope;
117 command is for
alarm when tracker
moves in.
When the tracker
moves in or out, it
will send an SMS
alarm to the
authorized phone
number for SOS.
W******,017,data
W******,117,data
data is the coordinates which include:
Lower-left X, Lower-left Y,Upper-right
X,Upper-right Y
For example,
11404.0000,E,2232.0010,N,11505.1234,E,23
33.5678,N
Note:
1. Lower-left X,Y (longitude and latitude)
should be smaller than Upper-right X,Y;
2. All longitudes and latitudes should be in
ASCII format as follows:-
Longitude: DDDMM.MMMM,E/W. 4 places
of decimal. ‘0’ is needed to be stuffed if no
value available.
Latitude: DDMM.MMMM,N/S. 4 places of
decimal. ‘0’ is needed to be stuffed if no
value available;
3. Send W******,017 or W******,117
without data to disable this function.
Presetting by SMS for GPRS tracking
Set ID for MT01 by SMS
W******,010,ID
Tracker ID must be less than
14 digits
Set APN by SMS
W******,011,APN,APN
Name, APN Password
APN Name, APN Password If
no password required, just
insert APN
name only;
APN defaulted as ‘CMNET’;
APN name + password not
over 39
characters.
Set IP Address and Port by
SMS
W******,012,IP, Port
IP: xxx.xxx.xxx.xxx
Port: [1,65536]
Enable GPRS Function
W******,013,X
X=0, close GPRS (default);
X=1, enable TCP
X=2, enable UDP
