Toptech MultiLoad II DIV-2 User Manual

46
MultiLoad II Lectro Count Remote Display Wiring 5.4.10
I/O DIGITAL/
ANALOG
I/O 2 METER
METER 0 METER 1
PORT 11/
PORT 0.10
+
-
5 – 28 Vdc
PORT 1.10
+
-
+
-
PORT 1.10.OUT
PORT 1.10.IN
PORT 11.OUT/
PORT 11.IN/
IN 1

OUT 2

IN 3

OUT 4

IN 5
OUT 6
IO_DA TB3
PORT 10
PORT 11
PORT 12
PORT 10/
PORT 0.10.OUT
PORT 0.10.IN
PORT 10.OUT/
PORT 10.IN/
IN 1

OUT 2

IN 3
OUT 4
IO_2M TB9
PORT
0.10
IN 1
OUT 2
IN 3

OUT 4

IO_2M TB9
PORT
1.10
≥ 500 mA
RESET
12 V COM
COUNT +
12 Vdc
Note: Use only model E1613. The Lectro Count +12Vdc, 12V common can be supplied by an external source.
Note (I/O DIGITAL/ ANALOG Only): Connect Port 10 to Lectro Count output pulse. Connect Port 11 to Lectro Count reset pulse.
Note (I/O 2 METER Only): Connect Port 0.10 to Lectro Count output pulse. Connect Port 1.10 to Lectro Count reset pulse.
