Toptech MultiLoad II DIV-2 User Manual

82
1.3 (ML)
07/25/2008
Added FCM I and II simulator description.
1.4 (ML)
12/19/2008
Added instructions required by update from UL508 to UL61010-1 that
customer is required to use a Class 2 power source when using the DC
power supply; described wiring partitions; described three types of PGM
W&M switches: shaft and magnetic bolts; first release of magnetic
switch construction; added table of torque requirements for all terminal
block plugs used to section 2.3 as required by UL.
1.4
(RCU)
12/19/2009
Added instructions required by update from UL508 to UL61010-1 that
customer is required to use a Class 2 power source when using the DC
power supply; described wiring partitions; described three types of PGM
W&M switches: shaft and magnetic bolts; first release of magnetic
switch construction; added table of torque requirements for all terminal
block plugs used to section 2.3 as required by UL; changed format to
mirror the new MultiLoad II format.
1.5 (ML)
10/02/2009
Removed FCM diagrams from chapter 4 and placed them in separate
FCM manual.
1.6
2/18/2011
Added wiring diagrams for 2 Meter I/O board; added wiring diagrams for
Lectro Count; added exploded drawing views for slotted card reader
construction; added Intertek requirements including Canadian required
French bilingual warnings; combined RCU II DIV-2 and ML II DIV-2 into
common manual; added ice shield maintenance.
1.6
3/11/2011
Editorial: pp. 29, 71, 73, 74; noted SD Card menu in Chapter 5.
10/29/2012
Corrected additive input mistake, updated mechanical drawings showing
slotted card holder
10/29/2012
Removed revision number—control by date.
10/29/2012
Added Hardware revision table.
10/29/2012
Clarified 4-20mA input wiring. Corrected COM2 label errors in diagram.
10/29/2012
Updated label, updated warnings, updated European DOC.
10/29/2012
Updated AC-PS board: COM0 5 pin, prerelease COM2 2wire 485
addition.
10/18/2013
Removed the wiring partition (figures 2.5 – 2.7).
10/18/2013
Updated EN standards to latest editions.
04/19/2016
Revised Declaration of Conformity (new directive dates in effect
4/20/2016). EC DOC became EU DOC.

Toptech MultiLoad II DIV-2 Specifications

General

Brand	Toptech
Model	MultiLoad II DIV-2
Category	Controller
Language	English
