TECHNICAL SPECIFICATIONS
Model Number
RAPTOR
500
RAPTOR
1000
RAPTOR
2000
RAPTOR
3000
RAPTOR
6000
Square drive ¾” 1” 1” 1” 1 1/2"
Min. Torque (ft/lbs) 78 148 231 484 714
Max. Torque (ft/lbs) 530 1030 2015 3070 5990
Min. Torque (nm) 106 201 313 656 968
Max. Torque (nm) 719 1396 2732 4162 8121
Height (in) 7.89" 7.89" 7.89" 7.89" 7.89"
Height (mm) 200.4 200.4 200.4 200.4 200.4
Square Drive (in) 0.75" 1.0" 1.0" 1.0" 1.5"
Square Drive (mm) 19.05 25.4 25.4 25.4 38.1
Dimension Length (in) 6.90" 8.87" 9.40" 11.62" 12.32"
Dimension Length (mm) 175.3 225.3 238.8 269.7 312.9
Diameter (in) 2.56" 2.85" 3.09" 3.75" 5.00"
Diameter (mm) 65.0 72.4 78.5 95.3 127.0
Weight (lbs) w/o arm 9 12 13.9 20 36
Weight (Kg) w/o arm 4.1 5.4 6.3 9.1 16.3
Performance Data (RPM)
- RPM @ 10 psi 16.5 7.0 3.5 1.75 1.25
- Tool Max Pressure 80psi 70psi 90psi 65psi 90psi
- RPM @ MAX psi 44 15 9.0 4.0 3.0
Requirements: Air Pressure 10-90 psi - Flow 44-55 CFM
