12
Air Reg.
PSI
RAPTOR
500
RAPTOR
1000
RAPTOR
2000
RAPTOR
3000
RAPTOR
6000
10
20
30
40
50
60
70
80
90
NOISE AND VIBRATIONS
Sound pressure level, measured in accordance OSHA & German Machinery-Noise-Information-
Leaet-3-GSGV requirements dated 18 Jan 1991, §1, (1 e) at maximum equipment performance is
just over 85 dB(A).
In accordance with §1, (2) of the same leaet sound pressure levels were measured for different
work cycles, with the sensor at a distance of 1 meter to the geometric center of the machine.
Vibrations become moderate just prior reaching the pre-set torque value.
On request RAPTOR Series Pneumatic Torque Wrenches with lower sound pressure levels (<85
dB(A)) are available as special modication. Because this modication comprises a sound
absorber, relevant torque values may change on given unit.
Beware of components under pressure. Inadvertent activation of the torque wrench may lead to
both a risk of injury as well as damage to property. When detaching the supply air hose always
shut off air to supply rst. Non-compliance with procedure may result in an out-of –control
supply hose thus risking personal injury and damage to property.
STORING YOUR RAPTOR SERIES TORQUE WRENCH
1. Shut off the pressurized air to the F/R/L by turning off the air to the F/R/L Unit.
2. Bleed off the air by depressing the toggle switch in either direction on the Pistol Grip.
3. Disconnect the supply hose from the F/R/L Unit, and disconnect the air hose at the RAPTOR
Series Pneumatic Torque Wrench.
4. If the RAPTOR Series Torque Wrench is not to be used for an extended period of time,
spray pneumatic lubricating oil into the RAPTOR Series Fitting. Reconnect the air hose and
supply hose to the F/R/L Unit air inlet tting. Cycle the F/R/L unit momentarily to ensure that
2-3 drops of lubricating oil has entered into the air motor. Then stop and shut-off the
system as previously mentioned above. Store your RAPTOR Series Torque Wrench
in the case that it was shipped in.
TECHNICAL SPECIFICATIONS
