13
ITEM DESCRIPTION PART # QT Y.
1 HANDLE AND MOTOR ASSEMBLY RP-AM19-ASSY 1
2 AIR MOTOR BALL RETAINER RP-AM19-41 1
3 STEEL BALL RP-CM-BB 35
4 SPUR GEAR RP-05-ST-G 3
5 1
ST
STAGE GEAR CAGE RP-05-ST1 1
6 SPUR GEAR RP-05-ST-G 3
7 2
ND
STAGE GEAR CAGE RP-05-ST2 1
8 HIGH SPEED ANNULUS RP-05-HSA 1
9 LONG HARDENED DOWEL RP-05-DOWEL 2
RP-500 Series Wrench
ITEM DESCRIPTION PART # QT Y.
10 THRUST WASHER RP-05-TW 2
11 NEEDLE ROLLER THRUST BEARING RP-05-NRB 1
12 DRIVE STAGE ASSEMBLY RP-05-DSTA 1
13 MAIN BEARING RP-05-MB 1
14 MAIN ANNULUS O-RING RP-CM-OR-MA 1
15 DRIVE ANNULUS O-RING RP-05-OR-DA 1
16 DRIVE ANNULUS SET SCREW RP-CM-SS-DA 4
17 DRIVE ANNULUS RP-05-DA 1
To Next Page
