14
RP-1000 Series Wrench with 3/4” Drive
ITEM DESCRIPTION PART # Q T Y.
1 HANDLE AND MOTOR ASSEMBLY RP-AM19-ASSY 1
2 AIR MOTOR BALL RETAINER RP-AM19-41 1
3 STEEL BALL RP-CM-BB 35
4 1
ST
STAGE SPUR GEAR RP-10-ST1-G 3
5 1
ST
STAGE GEAR CAGE RP-10-ST1 1
6 2
ND
STAGE SPUR GEAR RP-10-ST2-G 3
7 2
ND
STAGE GEAR CAGE RP-10-ST2 1
8 HIGH SPEED ANNULUS RP-10-HSA 1
ITEM DESCRIPTION PART # Q TY.
9 THRUST WASHER RP-10-TW 1
10 3
RD
STAGE GEAR CAGE ASSEMBLY RP-10-ST3A 1
11 DRIVE STAGE ASSEMBLY RP-10-DSTA 1
12 MAIN BEARING RP-10-MB 1
13 MAIN ANNULUS O-RING DRIVE RP-CM-OR-MA 1
14 DRIVE ANNULUS O-RING RP-10-OR-DA 1
15 DRIVE ANNULUS SET SCREW RP-CM-SS-DA 4
16 DRIVE ANNULUS RP-10-DA 1
To Next Page
