TorcUP RP-500 - Page 18

18
ITEM DESCRIPTION PART # QT Y.
1 HANDLE AND MOTOR ASSEMBLY RP-AM19-ASSY 1 2 AIR MOTOR BALL RETAINER RP-AM19-41 1 3 STEEL BALL RP-CM-BB 35 4 1
ST
STAGE SPUR GEAR RP-60-ST1-G 3
5 1
ST
STAGE GEAR CAGE RP-60-ST1 1
6 2
ND
STAGE SPUR GEAR RP-60-ST2-G 3
7 2
ND
STAGE GEAR CAGE RP-60-ST2 1
8 HIGH SPEED ANNULUS RP-60-HSA 1 9 MAIN ANNULUS O-RING RP-CM-OR-MA 2
10 3
RD
STAGE GEAR CAGE ASSEMBLY RP-60-ST3A 1
11 DRIVE ANNULUS SET SCREW RP-CM-SS-DA 4 12 DRIVE ANNULUS RP-60-DA 1
RP-6000 Series Wrench
ITEM DESCRIPTION PART # QT Y.
13 4
TH
STAGE GEAR CAGE ASSEMBLY RP-60-ST4A 1
14 DRIVE ANNULUS O-RING RP-60-OR-DA 1 15 4
TH
STAGE THRUST WASHER RP-60-ST4A-TW 1
16 DRIVE STAGE ASSEMBLY RP-60-DSTA 1 17 DRIVE STAGE THRUST WASHER RP-60-DSTA-TW 1 18 MAIN BUSHING BEARING RP-60-MB 1 19 ANNULUS HEAD O-RING RP-60-OR-AH 1 20 ANNULUS HEAD RP-60-AH 1 21 RETAINING RING RP-60-RR 1 22 ANNULUS CAP O-RING RP-60-OR-AC 1 23 ANNULUS CAP RP-60-AC 1 24 ANNULUS HEAD SCREW RP-60-AH-SCREW 6
