Operational and Maintenance Manual for TorcUP
RP-500, RP-1000, RP-2000, RP-3000 & RP-6000
Pneumatic Torque Wrenches
Version 1: 2016 March
The Raptor tools contain alloy components which may
cause a hazard in certain explosive environments.
General Description of TorcUP RAPTOR Series Pneumatic Torque Wrenches
The RAPTOR Series Pneumatic Torque Wrench provides torque settings of up to
6,000 Ft/lbs in clockwise and counter clockwise rotation, and it’s free joint execution allows for
random positioning of the tool.
Torque can be adjusted by regulating the amount of airow to the torque wrench and by
manipulating the air pressure regulating valve at the Filter/Regulator/Lubricator Unit (RAPTOR
F/R/L). The accuracy of maintaining a selected torque is subject to the stability of your air
supply. An airow of 40 to 55 CFMs guarantees optimum performance even within a
non-protected working environment.
NOTICE
Series RP-500, RP-1000, RP-2000, RP-3000 and RP-6000 Pneumatic Torque Wrenches are designed
for installing and removing threaded fasteners requiring precise high torque during bolt makeup and
maximum torque during bolt breakout.
TorcUP Inc. is not responsible for customer modication of tools or for applications on
which TorcUP Inc. was not consulted.
WARNING
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING TOOL.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION IN THIS
MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
The use of other than genuine TorcUP replacement parts may result in safety
hazards, decreased tool performance, increased maintenance, and may invalidate
all warranties. Repairs should be made only by authorized personnel. Consult
your nearest TorcUP Authorized Service Center.
Refer All Communications to the Nearest TorcUP Ofce or Distributor.
For Technical Support & Information Contact:
TorcUP Inc.
1025 Conroy Place, Easton, PA 18040 USA
Phone: +1 610-250-5800 Fax:+1 610-250-2700
email: sales@torcup.com
