Hydraulic-Filter-Restriction
Indicator
G453944
The
hydraulic-filter-restriction
indicator
alerts
you
when
the
hydraulic
filters
must
be
changed.
Power
Point
G453945
The
power
point
is
a
12
V
power
supply
for
electronic
devices.
3464-482A
Page
4–6
Product
Overview:
Controls
40
42
