Toro 03606A - Installing the Cutting Units

4
InstallingtheCuttingUnits
Partsneededforthisprocedure:
1
Rightfronthoseguide
1
Leftfronthoseguide
Procedure
1.Removethereelmotorsfromtheshipping
brackets.
Note:Discardtheshippingbrackets.
2.Removethecuttingunitsfromthecartons.
3.Assembleandadjustthecuttingunitsas
describedintheOperator'sManualforthe
cuttingunits.
4.Makesurethatthecounterweight(Figure4)is
installedtotheproperendofeachcuttingunit
asdescribedintheOperator'sManualforthe
cuttingunits.
g003320
Figure4
1.Counterweight
5.Mounttheturf-compensationspringtothesame
sideofthecuttingunitasthereel-drivemotor.
Repositiontheturf-compensationspringas
follows
Note:Allcuttingunitsareshippedwiththe
turf-compensationspringmountedtotheright
sideofthecuttingunit.
A.Removethe2carriageboltsandnuts
securingtherodbrackettothecutting-unit
tabs(Figure5).
g003949
Figure5
1.Turf-compensationspring3.Springtube
2.Rodbracket
B.Removetheangenutsecuringthe
spring-tubebolttothecarrier-frametab
(Figure5).Removetheassembly.
C.Mountthespring-tubebolttotheopposite
tabonthecarrierframeandsecurewiththe
angenut.
Note:Positiontheboltheadtotheouter
sideofthetabasshowninFigure6.
g003967
Figure6
1.Oppositecarrier-frametab
2.Rodbracket
D.Mounttherodbrackettothecutting-unit
tabswiththecarriageboltsandnuts(Figure
6).
Important:Oncuttingunit4(leftfront)
andcuttingunit5(rightfront),usethe
rodbracketmountingnutstoinstall
thehoseguidestothefrontofthe
cutting-unittabs(Figure7andFigure8).
Thehoseguidesshouldleantowardthe
centercuttingunit(Figure8andFigure
9).
14
