Note:Wheninstallingorremovingthe
cuttingunits,makesurethatthehairpin
cotterisinstalledinthespring-rodholenext
totherodbracket.Whennotinstallingor
removingthecuttingunits,thehairpincotter
mustbeinstalledintheholeintheendof
therod.
g030896
Figure7
1.Cuttingunit15.Cuttingunit5
2.Cuttingunit2
6.Reelmotor
3.Cuttingunit3
7.Weight
4.Cuttingunit4
g015160
Figure8
1.Hoseguide(cuttingunit4
shown)
3.Nut
2.Rodbracket
g019284
Figure9
1.Hoseguidesmustleantowardthecentercuttingunit.
