Hydraulic-ValveSolenoid
Functions
Usethelistbelowtoidentifyanddescribethedifferent
functionsofthesolenoidsinthehydraulicmanifold.
Eachsolenoidmustbeenergizedtoallowfunction
tooccur.
Solenoid
Function
SP2
Frontreelcircuit
SP1
Rearreelcircuit
SVRVLift/lowercuttingunits
SV1Lift/lowerfrontcuttingunits
SV3Lift/lowerrearcuttingunits
SV2
Raiseanycuttingunits
OperatingTips
Familiarization
Beforemowinggrass,practiceoperatingthemachine
inanopenarea.Startandstoptheengine.Operate
inforwardandreverse.Lowerandraisethecutting
unitsandengageanddisengagethereels.Whenyou
feelfamiliarwiththemachine,practiceoperatingup
anddownslopesatdifferentspeeds.
WarningSystem
Ifawarninglightcomesonduringoperation,stopthe
machineimmediatelyandcorrecttheproblembefore
continuingoperation.Seriousdamagecouldoccurif
youoperatethemachinewithamalfunction.
Mowing
Starttheengineandmovetheengine-speedswitch
totheFASTposition.MovetheEnable/Disableswitch
totheENABLEpositionandusetheLowerMow/Raise
levertocontrolthecuttingunits(thefrontcuttingunits
aretimedtolowerbeforetherearcuttingunits).T o
moveforwardandcutgrass,pressthetractionpedal
forward.
Transport
MovetheEnable/DisableswitchtotheDISABLE
positionandraisethecuttingunitstotheTRANSPORT
position.MovetheMow/Transportlevertothe
TRANSPORTposition.Becarefulwhendrivingbetween
objectssoyoudonotaccidentallydamagethe
machineorcuttingunits.Useextracarewhen
operatingthemachineonslopes.Driveslowlyand
avoidsharpturnsonslopestopreventrollovers.
Lowerthecuttingunitswhengoingdownhillfor
steeringcontrol.
43
